4.3″ inch 12 O’clock 480*272 LCD display for medical, Ebike, smart home, hand-held device, industrial, EV charger, Medical

PV043WQ-ITA4003-R is a 4.3″ inch 480*272 IPS round display from Elsun.

In addition, the 4.3″inch TFT module brightness is 260nits, and this 4.3″inch screen is 12 O’clock，it is a TN display. This Liquid Crystal Display has a built-in ST7282 controller,and it support resistive touch.
The material is RoHS-compliant.



1、Description

ELSUN 4.3″ inch 480*272 TFT module display supply very stable.

This 4.3″ inch supports RGB interface. enables fast and efficient communication between your Arduino and the display, ensuring smooth data transfer and real-time updates. This interface provides flexibility and compatibility with various Arduino models.

In addition, the 4.3″ inch TFT display module brightness is 260 nits, and this 4.3″ inch screen is 12 O’clock viewing type. For the touch part, we can also customize capacitive touch and resistive touch according to the customer requirements.



Powered by the ST7282 controller, this TFT LCD display delivers exceptional performance and reliability. Popular industries include IoT, industrial automation, consumer electronics, test and measurement instruments, and handheld devices.

Our displays are all RoHS compliant and adhere to strict environmental and safety standards.



2、Feature

1. Stable supply
2. 260brightness
3. Support resistive touch panel
4. Can custom resistive touch and capacitive touch
5. Medical, hand-held device, industrial



3、Product specification

Item	4.3inch TN/480*272/RGB/260nits/-20~+70/RTP
Model No.	PV043WQ-ITA4003-R
Resolution	480*272
Outline Dimension (mm)	105.5*67.20*4.05
Active Area (mm)	95.04*53.86
Viewing Angle	12 O’clock
Brightness	260
Interface	RGB
Backlight	4*2LED
Driving IC	ST7282
Operating Temperature	-20~70
Storage Temperature	-30~80
Touch screen	Can custom resistive and capacitive touch screen
Application	E-Bike,Medical, hand-held device, industrial，



4、Application

The 4.0 inch480*272 display module can be used for Electric motorcycle, hand-held device, industrial, smart home or others.

PV043WQ-ITA4003-R
